| Size | d | d1XN | H | H1 | L | C1 | C2 | D | W | D1 | (MPa) Wording Pressure |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 125 (5") | 125 | 23 x 8 | 360 | 230 | 64 | 216 | 210 | 280 | 190 | 185 | 1.0 |
| 150 (6") | 150 | 23 x 8 | 395 | 251 | 70 | 241.5 | 240 | 287 | 190 | 185 | 1.0 |
| 200 (8") | 200 | 23 x 8 | 475 | 302 | 88 | 298.5 | 290 | 345 | 245 | 300 | 1.0 |
| 250 (10") | 250 | 25 x 12 | 555 | 355 | 98 | 362 | 350 | 411 | 245 | 300 | 0.6 |
| 300 (12") | 300 | 25 x 12 | 640 | 398 | 108 | 431.8 | 400 | 485 | 245 | 300 | 0.6 |
| 350 (14") | 350 | 25 x 16 | 675 | 420 | 88 | 469 | 437 | 510 | 210 | 300 | 0.6 |
| 400 (16") | 400 | 25 x 16 | 730 | 445 | 98 | 516 | 494 | 570 | 210 | 410 | 0.6 |
| 450 (18") | 450 | 25 x 20 | 806 | 500 | 109 | 565 | 565 | 605 | 210 | 410 | 0.6 |
| 500 (20") | 500 | 25 x 20 | 830 | 490 | 135 | 620 | 620 | 666 | 280 | 410 | 0.6 |
