Pongee Industries Co., Ltd.
PUA-310/M is designed in accordance with ISO14443 type A standard to read or write the contactless card. This smart card reader utilizes Mifare® technology to read the memory cards, the advanced system to reduce the risk of tampered data or duplicated cards.
M0 Series：Mifare serial number (Unique ID.)
M1 Series：Mifare sector number assigned by Pegasus for specific customer.
M8 Series：Reading card number from Mifare block 8 by factory defaulted key.
U1 Series：USB, keyboard emulation(without any PC driver)
M0 Series：Mifare serial number (Unique ID.)
M1 Series：Mifare sector number assigned by Pegasus for specific customer.
M8 Series：Reading card number from Mifare block 8 by factory defaulted key.
U1 Series：USB, keyboard emulation(without any PC driver)
| Mifare® is a registered trade mark of Philips. |
|---|
Specifications
- Dimension: 118 (L) x 75(W) x 16(H) mm
- Weight: 250g ±10%
- Mounting: Surface mount, waterproof
- Reading range: 5~ 8 cm
- Frequency of operation: 13.56MHz
- Power supply: 5VDC±10%, 12VDC±10%
- Format: Wiegand( 26, 34, 44bits), ABA Track2, RS232, RS485, USB
- Operating Temperature: -15°C ~ 55°C
- Humidity: 20%~90% RH, Non condensation
- Mifare® is a registered trade mark of Philips.
- We reserve the right to change the specification without notice or obligation!
Certificate
- CE
Main Products
Personal, Lifts, Parking Access control, Time and attendance ,RFID modules , Biometric, Electric lock, Long Range RFID System
